12V/24V Automotive electronic water pump

Short Description:

Automotive electronic water pump is a water pump driven by an electric motor, used to circulate coolant in the car.
Different from the mechanical water pump of traditional fuel vehicles:
Mechanical water pump: driven by the engine belt, it only rotates when the engine is running
Electronic water pump: driven by electricity, can run as fast as you want, regardless of engine/motor speed
Nowadays, electronic water pumps are basically used in new energy vehicles and hybrid vehicles

Send email to us

Product Detail

Product Tags

12V/24V Automotive electronic water pump Description

1. Heat dissipation/insulation for the battery
During fast charging and high-speed driving, the battery heats up and the water pump circulates coolant to cool down; When winter is too cold, it helps to preheat the battery to make it more durable and have better endurance.
2. Provide heat dissipation for the drive motor and electronic control
The temperature of the motor and controller is very high when they are working, and if not cooled, they will directly overheat, limit power, or even burn out.
3. Cooling high-voltage components such as car chargers and DC/DC converters
During fast charging, these components generate significant heat and must be continuously cooled by a water pump.
4. Participate in the heating/cooling of the car's air conditioning system
Combined with the heat pump system, the waste heat from the battery and motor is sent to the car for heating, improving winter endurance.
5. Adjust speed according to demand, more energy-efficient
Slow down when the temperature is low, and fast up when the temperature is high, which is much more energy-efficient than mechanical water pumps.

12V/24V Automotive electronic water pump Parameter

Model	Rated voltage	Rated power	Rated Operating Condition	Protection Level
HS-030-221	DC12V	120W	900L/ H@11.5m	IP68
HS-030-262	DC24V	120W	900L/ H@11.5m	IP68
HS-030-262C	DC24V	120W	3000L/ H@6m	IP68
HS-030-272	DC24V	180W	2000L/ H@12m	IP68
HS-030-274	DC48V	180W	2000L/ H@12m	IP68

12V/24V Automotive electronic water pump advantages

1. High efficiency & energy saving
Electronically controlled speed, operates only as needed, significantly reduces power consumption compared to mechanical pumps.
Improves overall vehicle energy efficiency and extends driving range.
2. Precise thermal management
Real-time adjustable flow based on battery, motor and controller temperature.
Maintains optimal operating temperature (25–40°C) for key components, enhancing performance and lifespan.
3. Flexible layout & integration
Compact size, no mechanical transmission structure, easy to arrange in limited vehicle space.
Highly compatible with integrated thermal management systems.
4. Wide temperature adaptability
Works normally in extreme environments from -40°C to 125°C.
Supports battery preheating in low temperature and efficient heat dissipation during fast charging.
5. High reliability & long service life
Brushless motor design, no wear parts, low noise and vibration.
Long service life up to 20000 hours, meeting vehicle lifetime requirements.
6. Intelligent & safe operation
Supports CAN/PWM communication, real-time fault monitoring and protection.
High insulation performance, IP67/IP6K9K protection, ensuring safe use in high-voltage EV systems.
