4KW Commercial Vehicle Air Compressor 2.2KW Oil Free Piston Compressor 3KW Oilless Air Compressor

The oil free piston compressor, with its characteristic output of completely oil-free clean air, offers extensive application potential.

The main uses of oilless air compressor include:

1.A.Braking systems for electric vehicles:

Provides clean compressed air for electric buses, trucks, etc., ensuring safe and reliable brake air circuits while preventing contamination or blockage of valves and pipelines caused by oil residue.

2.B.Pneumatic door control for buses:

Drives door opening and closing mechanisms, offering responsive performance and long-term operation without failures due to oil accumulation, thereby extending maintenance cycles and enhancing system reliability.

3.C.Other onboard pneumatic equipment requiring high air quality:

Such as air suspension adjustment, airbag control, and pneumatic devices in medical rescue vehicles. It is particularly suitable for applications sensitive to oil content.

Customized solutions can be provided based on specific operating conditions and vehicle models.

The Piston Compressor offers the following key advantages:

A.Integrated Piston-Guiding Structure

The piston and guiding layer are designed as an integrated unit, which precisely controls the clearance between the piston and cylinder liner, effectively reducing friction and wear, thereby significantly extending the service life of piston components.

B.Excellent Thermal Management Performance

• Low exhaust temperature with strong environmental adaptability, ensuring stable operation under various working conditions.
• A rationally designed intake system allows ambient-temperature air to flow through the crankcase, providing continuous cooling to both the housing and piston.
• The cylinder liner is equipped with an independent peripheral cooling duct. A fan forces ambient air through this channel, enabling efficient active cooling.

C.High System Reliability

Through structural optimization and multi-path thermal management, the compressor maintains consistent performance during long-term continuous operation, resulting in extended maintenance intervals.
