NF Group 1.5KW Oil-free Piston Electric Air Compressor
Description
The TV2 Series Oil free Piston Air Compressor is a purpose-built solution for new energy vehicles (NEVs), engineered to deliver stable, continuous operation without any lubricating oil. It supplies clean, dry compressed air to critical vehicle subsystems—including braking, air suspension, and door actuation—ensuring precise actuation response, operational reliability, and simplified maintenance.
Clean, Oil-Free Compressed Air
A. Fully Lubricant-Free Operation
This Air Compressor operates entirely without lubricants; its output air is certified oil-free (per ISO 8573-1 Class 0), eliminating the risk of oil contamination in sensitive pneumatic circuits or end-use applications. It is especially suited for systems demanding ultra-high air purity, such as those found in battery thermal management or electronic control units.
B. Inherent Oil Elimination
By design, the compressed air contains zero lubricating oil—thereby avoiding performance-degrading phenomena including low-temperature oil solidification and high-humidity oil emulsification. This ensures consistent system functionality across diverse ambient conditions—from arctic cold starts to tropical humidity.
C. Enhanced System Efficiency via Oil-Free Air
Oil-free air prevents hydrocarbon residue buildup on heat transfer surfaces (e.g., air dryers, intercoolers, and heat exchangers), thereby maintaining optimal thermal performance, minimizing pressure drop, and contributing to improved overall energy efficiency of the compressed air system.
Preponderance of this type of electric air compressor
A. Highly Compact Integrated Architecture
A space-optimized, co-axial integration of the permanent magnet synchronous motor (PMSM) and compression cylinder enables a minimized footprint and reduced mass—ideal for constrained under-hood or chassis-mounted installations in NEVs.
B. Acoustically Optimized Operation
Through systematic refinement of the intake manifold, cylinder head geometry, and vibration-damping cylinder assembly, operational noise is consistently maintained below 72 dB(A) at 1 meter—meeting stringent OEM cabin comfort and urban noise regulations.
C. Advanced Cylinder Surface Engineering
The cylinder bore features a proprietary wear-resistant super coating (e.g., DLC or ceramic-reinforced composite), which enhances sealing integrity, minimizes frictional losses, suppresses micro-wear, and extends service life beyond 10,000 operating hours under typical NEV duty cycles.
D. Minimal Lifecycle Maintenance Requirement
Owing to its simplified mechanical architecture—featuring fewer moving parts, no oil sump, oil filters, or oil-change intervals—the compressor requires only periodic inspection of intake filters and mounting fasteners. This results in significantly reduced maintenance labor, downtime, and total cost of ownership (TCO).
Technical Parameter
|
Model |
TV2-1.5 |
|
| F.A.D(m3/min) |
0.16 |
|
| Working Pressure (bar) |
10 |
|
| Max.Pressure (bar) |
12 |
|
| Motor Type |
Sync. |
Async. |
| Rated Speed(RPM) |
1500 |
1435 |
| Rated Power (kW) |
1.5 |
1.5 |
| Rated Voltage (V) |
380V/220V |
380V |
| Protection Level |
IP67 |
|
| Air Inlet Connector |
φ25 |
|
| Air Outlet Connector |
M22x1.5 |
|
| Ambient Temp.（℃) |
65 |
|
| Vibation(mm/s) |
≤28 |
|
| Noise Level dB(a) |
≤75 |
|
Package And Delivery
Why Choose Us
Hebei Nanfeng Automobile Equipment (Group)Co.,Ltd was established in 1993,which is a group company with 6 factories and 1 international trading company.We are the biggest vehicle heating & cooling system manufacturer in China and the designated supplier of Chinese military vehicles.Our main products are high voltage coolant heater,electronic water pump,plate heat exchanger,parking heater,parking air conditioner,etc.
Our factory's production units are equipped with high tech machineries,strict quality control testing devices and a team of professional technicians and engineers endorsing the quality and authenticity of our products.
In 2006,our company has passed ISO/TS 16949:2002 quality management system certification.We also bagged the CE certificate and E-mark certificate making us among the only few companies in the world acquiring such high level certifications.Currently being the largest stakeholders in China,we hold a domestic market share of 40% and then we export them around the globe particularly in Asia,Europe and Americas.
Our dedication to fulfilling customer standards fuels constant innovation. Our experts are committed to designing and producing products that are precisely tailored to the needs of the Chinese market and customers worldwide.
