NF GROUP 180W Electric Pumps Hydrogen Fuel Cell Engine Pumps Electric Water Pump For New Energy Vehicle
Electric Pumps Description
NF Group Series 2 Cooling Water Pump – Product Introduction
An electronic water pump is an electrically driven liquid transfer device that significantly enhances temperature management efficiency by precisely controlling coolant flow. Compared to traditional mechanical water pumps driven by engine belts, electronic water pumps offer superior accuracy, reliability, and energy savings through intelligent control strategies. In the automotive field, electronic water pumps are widely used in engine cooling systems, and with the rapid development of new energy vehicles, their importance has become increasingly prominent across various vehicle types and thermal management applications.
NF Group Series 2 Electric Water Pump
NF Group's Series 2 electronic water pumps are engineered to deliver reliable and efficient cooling solutions for medium-duty new energy vehicles. Covering a power range from 80W to 180W, these pumps are available in both 12V and 24V voltage platforms, providing flexibility to meet diverse system requirements.
Cool Water Pump Primary Applications
The Series 2 pumps are specifically designed for auxiliary cooling and thermal management in medium-tonnage light and medium trucks powered by new energy.
They play a vital role in:
- 1. Air conditioning systems
- 2. Motor and electronic control units
- 3. Battery pack thermal management
- 4. Hydrogen fuel cell engine auxiliary cooling
Water Pump of Cooler Key Features
- 1. Compact and Lightweight Design: Optimized for space-constrained installations, the Series 2 pumps feature a miniaturized structure that reduces weight while maintaining robust performance.
- 2. High Efficiency: Advanced motor and hydraulic design ensure energy-efficient operation, contributing to overall vehicle range and system reliability.
- 3. Flexible Mounting Options: A variety of mounting brackets are available to accommodate different installation layouts, making these pumps ideal for applications with limited space.
Electric Pumps Technical Parameter
The parameters can be adjusted according to the customer's specific requirements.
| Serials | 2 Serial Pump (Low Power) | 2 Serial Pump(High Power) |
| Power Range | <120W | 130W~180W |
| Rated Voltage | 12V/24V | 12V/24V |
| Rated Point | 15L/min@11.5m 30L/min@5m 33L/min@5m | 26.7L/min@11m 33L/min@12m 20L/min@11m |
| Communication | CAN/PWM | CAN/PWM |
| Working Temperature Range | -40℃~100℃ | -40℃~100℃ |
| Storage Temperature Range | -40℃~125℃ | -40℃~125℃ |
| Medium Temperature | -40℃~90℃ | -40℃~90℃ |
| Outer Dimensions | 145mm*101mm*130mm | 167mm*93mm*139mm |
| Interface Size | Φ20mm/Φ25mm/Φ38mm | Φ25mm/Φ38mm |
| Weight | 1.12KG | 1.4KG |
If you wang more information, you are welcome to contact us directly.
Electric Pumps Package And Delivery
Why Choose Our Electric Pumps
Hebei Nanfeng Automobile Equipment (Group) Co., Ltd was established in 1993 and has grown into a comprehensive group company operating six specialized manufacturing factories. We are recognized as one of the main suppliers of new energy vehicle components in China and hold the distinction of being a designated supplier for Chinese military vehicles. Our extensive product portfolio includes high voltage coolant heaters, electronic water pumps, battery thermal management systems (BTMS), electric air compressors, EPS, EHPS, electric air conditioning compressors, three-way valves, parking heaters, parking air conditioners, plate heat exchangers, and more.
With a strong focus on quality and innovation, NF Group continues to provide cutting-edge thermal management solutions that meet the evolving needs of the new energy vehicle industry.
Our factory's production units are equipped with high tech machineries,strict quality control testing devices and a team of professional technicians and engineers endorsing the quality and authenticity of our products.
In 2006,our company has passed ISO/TS 16949:2002 quality management system certification.We also bagged the CE certificate and E-mark certificate making us among the only few companies in the world acquiring such high level certifications.Currently being the largest stakeholders in China,we hold a domestic market share of 40% and then we export them around the globe particularly in Asia,Europe and Americas.
Meeting the standards and demands of our customers have always been our top priority.It always encourages our experts to continuously brain storm,innovate,design and manufacture new products,impeccably suitable for the Chinese market and our customers from every nook of the world.
