NF Group 9000BTU Under-bunk Parking Air Conditioner for Caravan

Short Description:

This under-bench air conditioning unit provides both heating and cooling capabilities, making it suitable for recreational vehicles (RVs), panel vans, remote forest cabins, and other off-grid or mobile applications. The HB9000 model—our flagship under-bunk air conditioner—is engineered to match the performance, reliability, and build quality of the Dometic Freshwell 3000, while offering a more competitive price point.

Model: HB9000

Send email to us

Product Detail

Product Tags

Brief Introduction

NF under-bench caravan air conditioner has two functions of heating and cooling, suitable for RVs, vans, forest cabins, etc. Its rated cooling capacity is 9000BTU and rated heat pump capacity is 9500BTU. It has three power supply: 220-240v/50hz, 220v/60hz, 115v/60hz. Compared with the rooftop air conditioner, the under-bunk air conditioner occupies a smaller area and easy to install in the bottom storage area of an RV or camper, and provides an effective space-saving solution for vehicles up to 8 meters in length. The under-mounted installation not only adds no additional load to the roof, but also does not affect the vehicle's sunroof lighting, center of gravity or height. With quiet air circulation and a three-speed blower, it's easy and convenient to maintain the ideal environment.

Specifications

Model	NFHB9000
Rated Cooling Capacity	9000BTU(2500W)
Rated Heat Pump Capacity	9500BTU(2500W)
Extra Electric Heater	500W (but 115V/60Hz version has no heater)
Power(W)	cooling 900W/ heating 700W+500W (electric auxiliary heating)
Power Supply	220-240V/50Hz,220V/60Hz, 115V/60Hz
Current	cooling 4.1A/ heating 5.7A
Refrigerant	R410A
Compressor	vertical rotary type, Rechi or Samsung
System	One motor + 2 fans
Total Frame Material	one piece EPP metal base
Unit Sizes (LWH)	734398296 mm
Net Weight	27.8KG

Advantages

The advantages of this under bench air conditioner:
1. saving space;
2. low noise & low vibration;
3. air distributed equably through 3 vents all ove the room, more comfortable for users;
4. one-piece EPP frame with better sound/heat/vibration insulation, and so simple for faster installation and maintaince;
5. NF kept supplying Under-bench A/C unit for top brand exclusively over 10 years.
6. We have three control model, very convenient.
