NF Group High Voltage Coolant Heater 10KW HVCH 800V EV Coolant Heater
EV Coolant Heater Description
The thin‑film heater is an advanced high voltage coolant heater designed specifically as a heater for electric vehicles. Manufactured using physical vapor deposition and other semiconductor‑derived processes, it precisely deposits multiple functional layers onto an ultra‑thin substrate, creating a highly efficient resistive heating element with excellent uniformity and durability. It offers rapid thermal response, reaching target temperature within seconds.
Compared with conventional PTC heaters, thin‑film technology offers clear superiority. PTC heaters inherently lose power as resistance increases with temperature, leading to reduced output and wasted energy. In contrast, thin‑film heaters maintain a stable efficiency of 96–97% across a wide operating range. They enable precise power regulation via PWM and generate no inrush current at startup, protecting sensitive electronics. Their most compelling advantage is seamless compatibility with high‑voltage platforms: they support 400V to 1000V, far exceeding the limit of PTC units, which is essential for 800V architectures. Moreover, they are lead‑free and rare‑earth‑free, and their cost is now on par with PTC. This ensures consistent performance under varying loads.
In practical use, this device acts as a battery coolant heater, keeping the battery pack at 20–45 °C to preserve range and lifespan. As an EV liquid heater, it rapidly warms the cabin and defogs windows in cold conditions. It also serves as a pre‑heater for cold starts. This water high voltage heater is thus a vital component for electric vehicle thermal management.
As a trusted partner, Hebei Nanfeng Automobile Equipment (Group) Co., Ltd, established in 1993, is a group company with six factories. We are a leading supplier of new energy vehicle components in China and the designated supplier for Chinese military vehicles. Our main product portfolio includes high voltage coolant heater, electronic water pump, BTMS, electric air compressor, EPS, EHPS, electric air conditioning compressor, three‑way valve, parking heater, parking air conditioner, and plate heat exchanger. Recently, Nanfeng Group has launched a 10 kW thin‑film heater series. We warmly welcome inquiries from new and existing customers.
EV Coolant Heater Technical Parameter
| OE NO. | NFHVH-Q10 |
| Heating Power | 10kW@Water Outlet, 50°C, 10L/min |
| Working Voltage | 650V (400V~800V) |
| Control Voltage | 24V (18V-32V) |
| Medium Temperature Range | -40°C~90°C |
| Ambient temperature range | -40°C~120°C |
| Storage temperature range | -40°C~125°C |
| Insulation resistance | 1000VDC, 60s, insulation resistance≥ 100MΩ |
| Pressure rating | 3000VDC, 60s, Leakage current≤1.5mA |
| Communication Method | CAN 500K |
| Weight | 2.8kG |
| External dimensions (mm) | 325x210x65 |
| Water inlet pipe diameter (mm) | Ø20 |
| Control method | Power control/temperature control |
| Control frequency | 800Hz |
| Power control accuracy | 20W per step |
| Interlock function | Hardware Interlock |
| Altitude | 5000m |
| Recommended flow rate | 10L/min ~ 30L/min |
| Flow resistance | < 6kPa (10L/min, 23°C) |
| Operating pressure | ≤2.5bar |
| Peak pressure | ≤5.0bar |
EV Coolant Heater Package And Delivery
Why Choose Our EV Coolant Heater
With over 30 years of experience, Hebei Nanfeng Group (founded 1993) operates six factories and is both a major NEV parts supplier in China and a designated supplier for military vehicles. Beyond our flagship high‑voltage coolant heater, our diverse lineup includes electronic water pumps, BTMS, electric air compressors, EPS, EHPS, electric AC compressors, three‑way valves, parking heaters, parking air conditioners, and plate heat exchangers.
Our factory's production units are equipped with high tech machineries,strict quality control testing devices and a team of professional technicians and engineers endorsing the quality and authenticity of our products.
In 2006,our company has passed ISO/TS 16949:2002 quality management system certification.We also bagged the CE certificate and E-mark certificate making us among the only few companies in the world acquiring such high level certifications.Currently being the largest stakeholders in China,we hold a domestic market share of 40% and then we export them around the globe particularly in Asia,Europe and Americas.
Meeting the standards and demands of our customers have always been our top priority.It always encourages our experts to continuously brain storm,innovate,design and manufacture new products,impeccably suitable for the Chinese market and our customers from every nook of the world.
