NF GROUP Electric Car Window Defroster 6kW High Voltage Electric Defroster
Electric Bus Defroster Description
The Water-Electric Integrated Defroster from NF GROUP is a dual‑purpose defrosting unit designed for commercial and new energy vehicles.
It integrates a high‑voltage relay and offers two independent heat sources: PTC (Positive Temperature Coefficient) electric heating and waste heat from the engine or battery coolant circuit.
These two heating modes can be used separately or simultaneously, providing exceptional flexibility and thermal efficiency.
Electric defroster for electric buses Key Advantages
- High-performance brushless fan – Rated for over 20,000 hours of continuous operation, ensuring long‑term reliability.
- Extended PTC dry heating life – The PTC element can operate in dry conditions for more than 500 hours without performance degradation.
- EU compliance – The high voltage electric bus defroster meets strict European standards and has obtained the E‑Mark certificate, certifying its legality and safety for the European market.
Electric Bus Electric Defroster Performance Features
- Integrated water‑electric design – Accommodates both high‑voltage electric heating and coolant heating simultaneously or independently, offering maximum flexibility and high thermal efficiency.
- Separate layout – The PTC heating core and the water tank are arranged separately, significantly improving safety.
- IP67 protection – The PTC heating element is rated IP67, providing excellent resistance to dust and temporary immersion, which enhances safety in harsh environments.
- Compact structure – Easy to install and space‑saving, ideal for vehicles with limited mounting space.
NF GROUP offers full customization for this water‑electric integrated defroster.
Based on customer requirements, we can adjust high voltage electric defroster key parameters such as heating capacity, voltage range, dimensions, mounting configuration, and even the external shape.
Whether you need a variant for a specific vehicle platform or a completely tailored solution, our engineering team is ready to support you.
We welcome inquiries from both existing and new customers.
Please contact us to discuss your Electric defroster project needs or request a detailed technical datasheet.
Electric Bus Defroster Technical Parameter
| Parameter | Value |
|---|---|
| Motor power | 180W |
| Ambient temperature range | -40°C to +50°C |
| Electric heater rated voltage | DC600V (operating range DC520V~DC680V) |
| Motor rated voltage | DC24V (operating range DC16V~DC32V) |
| Nominal heating capacity (electric) | 4kW ±10% (at DC600V, 20°C inlet air) |
| Water heating capacity | 7kW ±10% |
| Fan rated power | 180W ±10% |
| Fan rated current | ≤8A |
| Surface finish | Matte black coating |
| Overheat protection | Two‑stage thermostat (90°C normally closed + 150°C manual reset) |
| Fan speed control | High speed: both high and low wires connected to DC24V; Low speed: only low wire to DC24V |
| External lead length | 500mm ±50mm |
| External air filter | Welded to the center of the bottom surface |
| Electrical connectors | Waterproof connectors with dustproof caps on harness ends |
| Wire requirements | Flame‑retardant, excellent insulation, heat‑resistant up to 125°C (minimum) |
Electric Bus Defroster Package And Delivery
Why Choose Our Electric Bus Defroster
Hebei Nanfeng Automobile Equipment (Group)Co.,Ltd was established in 1993,which is a group company with 6 factories and 1 international trading company.We are the biggest vehicle heating & cooling system manufacturer in China and the designated supplier of Chinese military vehicles.Our main products are high voltage coolant heater,electronic water pump,plate heat exchanger,parking heater,parking air conditioner,etc.
Our factory's production units are equipped with high tech machineries,strict quality control testing devices and a team of professional technicians and engineers endorsing the quality and authenticity of our products.
In 2006,our company has passed ISO/TS 16949:2002 quality management system certification.We also bagged the CE certificate and E-mark certificate making us among the only few companies in the world acquiring such high level certifications.Currently being the largest stakeholders in China,we hold a domestic market share of 40% and then we export them around the globe particularly in Asia,Europe and Americas.
Meeting the exacting standards and evolving demands of our customers is our core mission. This commitment drives our team of experts to continually innovate, design, and manufacture high-quality products that are ideally suited for both the Chinese market and our diverse international clientele.
